How do I configure the WWVDS detection camera?

This article discusses configuring the WWVDS detection camera using the web interface.

Procedure

  1. Access the WWVDS Web Interface.
  2. Navigate to Configuration —> Detection Camera.
    1. You will see the optical video stream settings for the confirmation camera (Video Stream 1):

If you do not see any video streams configured, click Add to create a new video stream from the connected bi-spectrum camera. Configure this new stream using the same settings as shown below:

  1. Ensure, an RTSP connection line is specified for channel 1, similar to the following (replace 10.1.10.77 with the IP address you assigned to the detection camera). The asterisks (******) mask the password, in the example above, the admin user password.
rtsp://admin:******@10.1.10.77:554/snl/live/1/1
  1. Click Save after making changes.
  2. Click Video Stream 2 to check the thermal video stream settings. Verify the second (thermal) video stream points to channel 2 of the bi-spectrum camera (replace 10.1.10.77 with the IP address you assigned to the detection camera):
rtsp://admin:******@10.1.10.77:554/snl/live/2/1
  1. Click Save after making changes. Once you have completed the configuration process, you should be able to view live video feeds from both the optical and thermal sensors of the confirmation camera.
